Monel is a group of nickel alloys that contain copper, iron, and small amounts of other elements such as manganese, silicon, and carbon. Monel alloys are known for their excellent corrosion resistance, high strength, and good mechanical properties at elevated temperatures. Here is a brief description of Monel products such as pipe, tube, flange, fastener, fittings, and round bar
Chemical Compositions
| Monel Grade/Trade Name | ASTM/AISI Alloy Type | UNS No. | %Ni | %Cu | %Fe | %Mn | %Al | %Ti | %Si |
| 400 | B 127/ B 164 | N04400 | Min. 63 | 28-34 | Max 2.5 | Max 2.0 | Max 0.5 | ||
| 401 | N04401 | Min. 63 | 28-34 | Max 2.5 | Max 2.0 | Max 0.5 | |||
| 404 | N04404 | 52-57 | Remaining | Max 0.5 | Max 0.1 | Max 0.05 | Max 0.1 | ||
| 405 | B 164 | N04405 | Min. 63 | 28-34 | Max 2.5 | Max 2.0 | Max 0.5 | ||
| K500 | B 865 | N05500 | Min. 63 | 27-33 | Max 2.0 | Max 1.5 | 2.3-3.15 | 0.35-0.85 | Max 0.5 |
Mechanical Properties
| Form | Condition | Tensile Strength (ksi) | Yield Strength (ksi) | % Elongation | Brinell hardness | Rockwell B Hardness | Tensile Strength (Mpa) | Yield Strength (Mpa) |
| Rod and Bar | Annealed | 75-90 | 25-50 | 60-35 | 110-149 | 60-80 | 517-620 | 172-345 |
| Rod and Bar | Hot-Finished (except Hexagons over 2 1/8 inches and Angles) |
80-110 | 40-100 | 60-30 | 140-241 | 75-100 | 552-758 | 276-690 |
| Rod and Bar | Hot-Finished Hexagons over 2 1/8 inches and Angles |
75-100 | 30-55 | 50-30 | 130-184 | 72-90 | 517-690 | 207-379 |
| Rod and Bar | Cold-Drawn, Stress-Relieved | 84-120 | 55-100 | 40-22 | 160-225 | 85-20C | 579-827 | 379-690 |
| Plate | Hot Rolled | 75-95 | 40-75 | 45-30 | 125-215 | 70-96 | 517-655 | 276-517 |
| Plate | Hot Rolled, Annealed | 70-85 | 28-50 | 50-35 | 110-140 | 60-76 | 482-586 | 193-345 |
| Sheet | Annealed | 70-85 | 30-45 | 45-35 | 65-80 | 482-586 | 207-310 | |
| Sheet | Cold Rolled, hard | 100-120 | 90-110 | 15-02 | Min. 93 | 690-827 | 621-758 | |
| Cold Rolled Strip | Annealed | 70-85 | 25-45 | 55-35 | Max. 68 | 482-586 | 172-310 | |
| Cold Rolled Strip | Spring Temper | 100-140 | 90-130 | 15-02 | Min. 98 | 690-965 | 621-896 | |
| Seamless pipe and tube | Cold Drawn, Annealed | 70-85 | 25-45 | 50-35 | Max 75 | 482-586 | 172-310 | |
| Seamless pipe and tube | Cold Drawn, Stress Relieved | 100-140 | 55-100 | 35-15 | 85-100 | 586-827 | 379-690 | |
| Cold Drawn Wire | Annealed | 70-95 | 30-55 | 45-25 | 482-655 | 207-379 |
